Description
OPEN THIS TAB TO SEE MALOSSI BELT DIMENSIONS
 |
CODE |
A Width mm |
B Thickness mm |
C External size mm |
D Angle |
|---|---|---|---|---|
| 61 7224 | 10 | 8 | 927 | 36° |
| 61 7226 | 10 | 8 | 940 | 36° |
| 61 7227 | 13 | 6.5 | 978 | 34° |
| 61 7222 | 13 | 6.5 | 1089 | 34° |
| 61 7314 | 13 | 6.5 | 1143 | 34° |
| 61 7219 | 13 | 8 | 870 | 38° |
| 61 7223 | 13.4 | 6.5 | 1060 | 34° |
| 6112745 | 14.5 | 8 | 819 | 30° |
| 61 7220 | 15 | 8 | 747 | 30° |
| 61 7216 | 15 | 8 | 793 | 30° |
| 61 7233 | 15 | 8 | 853 | 32° |
| 61 7213 | 15.3 | 8 | 642 | 32° |
| 6111164 | 16 | 8 | 832 | 26° |
| 61 7214 | 16 | 8 | 1180 | 32° |
| 6112730 | 16.5 | 8 | 745 | 30° |
| 6112741 | 16.5 | 8 | 796 | 30° |
| 61 9832 | 17 | 8 | 802 | 30° |
| 61 9829 | 17.5 | 8 | 723 | 30° |
| 61 8396 | 18 | 8 | 703 | 32° |
| 6112735 | 18 | 8 | 769 | 32° |
| 6117248 | 18 | 8 | 798 | 30° |
| 61 9221 | 18 | 9 | 838 | 32° |
| 6116844 | 18.4 | 8 | 785 | 30° |
| 6111246 | 18.5 | 8 | 727 | 30° |
| 61 9830 | 18.5 | 8 | 834 | 30° |
| 6116748 | 18.5 | 8.5 | 794 | 30° |
| 6116889 | 18.7 | 8 | 810 | 30° |
| 6117253 | 19.5 | 9 | 924 | 28° |
| 6114127 | 22.3 | 10.5 | 924 | 30° |
| 6115676 | 22.7 | 10.5 | 931 | 28° |
| 6117244 | 25.5 | 10.5 | 902 |
31° |
| CODE | A Width mm |
B Thickness mm |
C External size mm |
D Angle |
|---|---|---|---|---|
| 6116830 | 13 | 6.5 | 974 | 30° |
| 6117005 | 13 | 6.5 | 1056 | 30° |
| 6117006 | 13 | 6.5 | 1134 | 30° |
| 61 7215 | 15.3 | 8 | 652 | 32° |
| 6111152 | 16 | 8 | 828 | 26° |
| 61 7231 | 16.5 | 8 | 670 | 30° |
| 61 7664 | 16.5 | 8 | 703 | 30° |
| 6117010 | 16.6 | 8 | 745 | 28° |
| 6117087 | 16.9 | 8 | 800 | 28° |
| 61 7229 | 17 | 8 | 735 | 30° |
| 61 9591 | 17 | 8 | 781 | 30° |
| 61 7665 | 17.5 | 8 | 724 | 30° |
| 61 7587 | 17.5 | 8 | 804 | 30° |
| 6111108 | 17.5 | 8 | 815 | 30° |
| 61 7211 | 17.5 | 9 | 675 | 32° |
| 61 8779 | 17.5 | 9.5 | 820 | 30° |
| 6112959 | 17.8 | 10 | 778 | 28° |
| 61 7221 | 18 | 8 | 705 | 32° |
| 6113501 | 18 | 9 | 743 | 30° |
| 6113397 | 18 | 9.5 | 680 | 30° |
| 6115822 | 18 | 10.2 | 782 | 28° |
| 6113503 | 18.2 | 8 | 683 | 30° |
| 6111153 | 18.2 | 8 | 734 | 30° |
| 6117086 | 18.4 | 8 | 769 | 30° |
| 6116424 | 18.5 | 8 | 765 | 30° |
| 6111294 | 18.5 | 8 | 779 | 30° |
| 61 9535 | 18.5 | 8 | 830 | 30° |
| 6116215 | 18.8 | 10.6 | 814 | 28° |
| 6116671 | 19 | 8 | 769 | 30° |
| 6117451 | 19 | 9.7 | 939 | 30° |
| 6115104 | 19 | 10.2 | 745 | 28° |
| 6115668 | 19 | 10.2 | 815 | 28° |
| 6117452 | 19.2 | 10 | 833 | 31° |
| 6117453 | 19.8 | 9.3 | 806 | 30° |
| 6116148 | 19.9 | 9.7 | 785 | 30° |
| 6116665 | 20 | 9.5 | 795.5 | 30° |
| 6115275 | 20.7 | 9.7 | 884 | 32° |
| 6116419 | 22 | 9.3 | 796 | 28° |
| 6116666 | 22 | 9.3 | 809 | 28° |
| 6116101 | 22 | 9.3 | 832 | 28° |
| 6113059 | 22 | 9.3 | 918 | 28° |
| 6116667 | 22 | 9.7 | 880 | 28° |
| 6113502 | 22 | 10 | 849 | 30° |
| 6117009 | 22 | 10.5 | 830 | 28° |
| 6115666 | 22 | 13 | 824 | 28° |
| 6116697 | 22 | 13 | 945 | 28° |
| 61 9956 | 22.2 | 11 | 888 | 30° |
| 61 9584 | 22.5 | 10 | 840 | 30° |
| 6116422 | 22.5 | 10 | 920 | 30° |
| 6116117 | 22.5 | 10.5 | 814 | 30° |
| 6116118 | 22.5 | 10.5 | 937 | 30° |
| 6112714 | 22.5 | 11 | 1008 | 30° |
| 6113027 | 22.6 | 13 | 834 | 28° |
| 6116069 | 22.6 | 13 | 955 | 28° |
| 6116094 | 23 | 11.4 | 871 | 28° |
| 6112713 | 23 | 14.8 | 947 | 28° |
| 6116421 | 23.2 | 10.5 | 949 | 30° |
| 6117478 | 23.4 | 11.7 | 822 | 28° |
| 6115276 | 24 | 10.2 | 987 | 30° |
| 6116568 | 24 | 10.5 | 912 | 30° |
| 6113028 | 24 | 11.4 | 995 | 32° |
| 6113021 | 24 | 15 | 1041 | 30° |
| 6117205 | 24.4 | 10.6 | 924 | 32° |
| 6115277 | 25.2 | 14.7 | 1004 | 30° |
| 6115279 | 26 | 13.6 | 1093 | 28° |
| 6113396 | 26 | 14.8 | 1008 | 28° |
| 6115278 | 26.2 | 10.5 | 969 | 31° |
| 6113590 | 26.4 | 13 | 1026 | 32° |
| 6113500 | 26.5 | 14.4 | 1244 | 30° |
| 6115803 | 26.5 | 14.4 | 1262 | 30° |
| 6115125 | 28.7 | 16 | 1044 | 28° |
| 6116100 | 28.9 | 14.7 | 1036 | 28° |
| 6116079 | 30 | 14.7 | 1018 | 26° |
| 6112960 | 30 | 15 | 912 | 26° |
| 6115280 | 30.1 | 14.7 | 931 | 28° |
| 6116011 | 31.2 | 16 | 908 | 28° |
| 6114674 | 32.2 | 14.9 | 892 | 28° |
| 6118071 | 32.2 | 14.9 | 892 | 28° |
| 6115687 | 32.4 | 16.9 | 894 | 28° |
| 6115126 | 32.7 | 16.9 | 960 | 28° |
