Electric Water Pump - Malossi
CONTACT US TO VERIFY AVAILABILITY
Description
*** PRODUCT IS DESIGNED FOR ON ROAD USAGE - MANY USE FOR OFF ROAD RACING BUT PLEASE MAKE PRECAUTIONS TO PROTECT IT FROM DIRT - WATER - DEBRIS TO PREVENT PREMATURE FAILURE ***
SPECIFICATIONS
The pump is enclosed in a rugged PPC, a light and unbreakable polymer, resistant to high temperatures, acids and fuels.It uses a 12V feeder supplied by the battery and has a robust electric motor with brushless excitation technology.
Traditional mechanical cooling pumps are normally driven by the crankshaft and follow the rpm of the engine. For this reason, they are not always able to supply the correct flow for proper cooling, e.g. low engine speeds and high loads.
ENERGY PUMP is equipped with an electronic card (electronic switching WCP) which, combined with a dedicated controller, allows you to adjust the flow rate to the cooling requirements of the engine, regardless of the conditions of the engine speed and of the applied loads.
This means that the engine always operates with optimal coolant temperatures.
|
Units |
||
|
Voltage Range |
V |
9 ÷ 15 |
|
Nominal Voltage |
V |
12 |
|
Pumping Capacity @ 100 mbar |
L/h |
1200 |
|
Current Consumption (12V, 100 mbar, 23°C) |
A |
1.6 |
|
Operating Temperature |
°C |
-40 ÷ 135 |
|
Nominal RPM (12V, 100 mbar, 23° C) |
Rpm |
3200 |
|
Protection Class |
IP55 |
