DRR DRX 50R

*** R CYLINDERS ARE NOT INSTALLED IF PURCHASING A NON ASSEMBLED UNIT

*** NON ASSEMBLED UNITS HAVE NO WARRANTY

*** UNIT COLORS CAN VARY FROM SHIPMENT TO SHIPMENT - do not assume which color you are getting ***

SPECIFICATIONS

• ENGINE
• SIZE 50cc Water Cooled
• TYPE Aluminum Cylinder by DRR
• STROKE 2-Stroke
• STARTING SYSTEM Electric Starter with Kickstarter Backup
• FEATURES Throttle Limiter
• POWERTRAIN
• TRANSMISSION CVT
• CHASSIS
• FRONT SUSPENSION Dual A-Arm Gas Charged Adjustable AMA-Compliant Piggyback Adjustable Shocks
• FRONT BRAKES Closed Hydraulic 7.25" Dual Disc Wave Rotor Braking System
• REAR BRAKES Super Stop Foot Brake System with Single 7.25" Cross Drilled Wave Rotor
• REAR SUSPENSION Remote Reservoir Adjustable Mono-Shock DRR Works Racing-Style Square Tube Swing Arm
• FRONT TIRES 21x7x10
• REAR TIRES 17x7x7
• FEATURES Red Mallossi-Style Torsion and Clutch Springs
• FEATURES 19-Tooth Slipper Sprocket

SAFETY

FEATURES US Forestry Approved Spark Arrestor
FEATURES Fully-Enclosed Floorboards
FEATURES Daytime Running Light
FEATURES Racing Safety Tether
FEATURES Gripper Seat
DIMENSIONS
WIDTH 41" (104.14 cm)
SEAT HEIGHT 25" (63.5 cm)
WHEELBASE 40" (101.6 cm)
DRY WEIGHT 232 lbs
LENGTH 59" (149.86 cm)
HEIGHT 39" (99.06 cm)
GROUND CLEARANCE 8"

ATV ADVISORIES

NEVER permit children under age 6 to operate any ATV. 50cc to 70cc ATVs are only recommneded for riders 6 years and older and can only be used with adult supervision. Operation of a 50cc to 70cc ATV by children under the age of 6 increases the risk of severe injury or death. Adult supervision required for children under age 16. In addition all Y6 ATVs are speed restricted and should never be altered in such a way which would remove the speed restrictions.

Operation of a 90cc ATV by children under the age of 12 increases the risk of severe injury or death. Adult supervision required for children under age 16. NEVER permit children under age 12 to operate this ATV. in addition all Y12 ATVs are speed restricted and should never be altered in such a way which would remove the speed restrictions. ATVS with engines over 90cc are recommended for use only for riders 16 years and older.

DRR® recommends that all riders take an approved safety course before riding. For safety course information contact your dealer or call (866) 847-4571 for safety training information. ATVS can be hazardous to operate and improper ATV use can result in severe injury or death.

For your safety: always use approved helmet, goggles and protective gear. Never use on public roads. Never carry passengers. Never use with drugs or alcohol. Never operate without proper training or instruction. Never operate at speeds too fast for your skills or the conditions. Never operate on public roads where a collision can occur with another vehicle. Never operate with a passenger. Passengers affect balance and steering increasing the risk of losing control. Always use proper riding techniques to avoid vehicle overturns on hills and rough terrain and in turns. Always avoid paved surfaces. Pavement may seriously affect handling and control.

Locate and read the owner's manual.


1Prices subject to change at any time without notice. Contact a DRR® Authorized Dealership for current prices and prices not listed. Dealer may choose to substitute parts. Additional options may be available at additional charges. Taxes, delivery and dealer setup charges not included.

2Please read all advisories and the manual before operating any vehicle.

3Pre-approved financing provided by Nextep Funding. Financing provided based on credit worthiness. DRR® USA, Inc. does not guarantee that financing provided by Nextep Funding will cover the entire cost of the vehicle. Other financing options provided at point of sale.

Specifications subject to change without notice.
