28mm Keihin PE Carburetor
SKU: CRB0048
$349.99
By KEIHIN
Description
- With a wide selection of venturi sizes between 20mm and 38mm, you are able to custom match your performance requirement.
- Chrome plated round slide.
- High performance at an economical price.
PE Carburetors Standard Jetting
| SIZE | MAIN JET | SLOW JET | JET NEEDLE | THR. VALVE |
|---|---|---|---|---|
| PE 20MM R69 | #100 | #58 | 36S00 | #4.0 |
| PE 22MM 18S | #102 | #40 | 94D00 | #3.5 |
| PE 24MM S14 | #115 | #52 | G1427-36S (REF) | #3.0 |
| PE 26MM 78P | #142 | #40 | 46JFH | #3.0 |
| PE 28MM R37 | #125 | #40 | 46LGN | #2.0 |
| PE 30MM 79P | #130 | #55 | 47CGJ | #3.0 |
| PE 34MM 04K | #152 | #48 | 48DGL | #3.0 |
| PE 36MM 80P | #160 | #60 | 48DGJ | #3.0 |
| PE 38MM R50 | #160 | #50 | 48AJM | #3.5 |
PE Carburetors Dimensions
| SIZE | A | B | C | D |
|---|---|---|---|---|
| PE 20MM | 31 | 46 | 83 | 136.0 |
| PE 22MM | 31 | 46 | 83 | 136.0 |
| PE 24MM | 31 | 46 | 83 | 142.1 |
| PE 26MM | 33 | 48 | 83 | 140.5 |
| PE 28MM | 35 | 50 | 83 | 150.9 |
| PE 30MM | 37 | 54 | 95 | 157.8 |
| PE 34MM | 41 | 58 | 95 | 174.5 |
| PE 36MM | 43 | 61 | 95 | 178.0 |
| PE 38MM | 44 | 62 | 95 | 182.5 |
KKeihin PE28mm Roundslide Carb
(#125 Main #40 Pilot)
- With a wide selection of venturi sizes between 20mm and 38mm, you are able to custom match your performance requirement.
- Chrome plated round slide.
- High performance at an economical price.
Download the Technical Info (PDF)
PE Carburetors Standard Jetting
| SIZE | MAIN JET | SLOW JET | JET NEEDLE | THR. VALVE |
|---|---|---|---|---|
| PE 20MM R69 | #100 | #58 | 36S00 | #4.0 |
| PE 22MM 18S | #102 | #40 | 94D00 | #3.5 |
| PE 24MM S14 | #115 | #52 | G1427-36S (REF) | #3.0 |
| PE 26MM 78P | #142 | #40 | 46JFH | #3.0 |
| PE 28MM R37 | #125 | #40 | 46LGN | #2.0 |
| PE 30MM 79P | #130 | #55 | 47CGJ | #3.0 |
| PE 34MM 04K | #152 | #48 | 48DGL | #3.0 |
| PE 36MM 80P | #160 | #60 | 48DGJ | #3.0 |
| PE 38MM R50 | #160 | #50 | 48AJM | #3.5 |
PE Carburetors Dimensions
| SIZE | A | B | C | D |
|---|---|---|---|---|
| PE 20MM | 31 | 46 | 83 | 136.0 |
| PE 22MM | 31 | 46 | 83 | 136.0 |
| PE 24MM | 31 | 46 | 83 | 142.1 |
| PE 26MM | 33 | 48 | 83 | 140.5 |
| PE 28MM | 35 | 50 | 83 | 150.9 |
| PE 30MM | 37 | 54 | 95 | 157.8 |
| PE 34MM | 41 | 58 | 95 | 174.5 |
| PE 36MM | 43 | 61 | 95 | 178.0 |
| PE 38MM | 44 | 62 | 95 | 182.5 |
