22mm Keihin PE22 Carburetor

SKU 016-123
by KEIHIN
Original price $258.00 - Original price $258.00
Original price
$258.00
$258.00 - $258.00
Current price $258.00
Keihin PE 22 Carburetor 016-123 $149.95
(#40 Pilot #102 Main)

PE Features:

  • With a wide selection of venturi sizes between 20mm and 38mm, you are able to custom match your performance requirement.
  • Chrome plated round slide.
  • High performance at an economical price.

Download the Technical Info (PDF)


PE Carburetors Standard Jetting

SIZE MAIN JET SLOW JET JET NEEDLE THR. VALVE
PE 20MM R69 #100 #58 36S00 #4.0
PE 22MM 18S #102 #40 94D00 #3.5
PE 24MM S14 #115 #52 G1427-36S (REF) #3.0
PE 26MM 78P #142 #40 46JFH #3.0
PE 28MM R37 #125 #40 46LGN #2.0
PE 30MM 79P #130 #55 47CGJ #3.0
PE 34MM 04K #152 #48 48DGL #3.0
PE 36MM 80P #160 #60 48DGJ #3.0
PE 38MM R50 #160 #50 48AJM #3.5

PE Carburetors Dimensions

SIZE A B C D
PE 20MM 31 46 83 136.0
PE 22MM 31 46 83 136.0
PE 24MM 31 46 83 142.1
PE 26MM 33 48 83 140.5
PE 28MM 35 50 83 150.9
PE 30MM 37 54 95 157.8
PE 34MM 41 58 95 174.5
PE 36MM 43 61 95 178.0
PE 38MM 44 62 95 182.5

* Images - prices - features may change at anytime without notice
