24mm Keihin PE24 Carburetor

by KEIHIN
SKU 016.126
Original price $245.00 - Original price $245.00
Original price
$245.00
$245.00 - $245.00
Current price $245.00
  • With a wide selection of venturi sizes between 20mm and 38mm, you are able to custom match your performance requirement.
  • Chrome plated round slide.
  • High performance at an economical price.

PE Carburetors Standard Jetting

SIZE MAIN JET SLOW JET JET NEEDLE THR. VALVE
PE 20MM R69 #100 #58 36S00 #4.0
PE 22MM 18S #102 #40 94D00 #3.5
PE 24MM S14 #115 #52 G1427-36S (REF) #3.0
PE 26MM 78P #142 #40 46JFH #3.0
PE 28MM R37 #125 #40 46LGN #2.0
PE 30MM 79P #130 #55 47CGJ #3.0
PE 34MM 04K #152 #48 48DGL #3.0
PE 36MM 80P #160 #60 48DGJ #3.0
PE 38MM R50 #160 #50 48AJM #3.5


PE Carburetors Dimensions

SIZE A B C D
PE 20MM 31 46 83 136.0
PE 22MM 31 46 83 136.0
PE 24MM 31 46 83 142.1
PE 26MM 33 48 83 140.5
PE 28MM 35 50 83 150.9
PE 30MM 37 54 95 157.8
PE 34MM 41 58 95 174.5
PE 36MM 43 61 95 178.0
PE 38MM 44 62 95 182.5
    Keihin PE 24 Round Slide Carburetor
    (#52 Pilot #115 Main)
    • With a wide selection of venturi sizes between 20mm and 38mm, you are able to custom match your performance requirement.
    • Chrome plated round slide.
    • High performance at an economical price.

    Download the Technical Info (PDF)


    PE Carburetors Standard Jetting

    SIZE MAIN JET SLOW JET JET NEEDLE THR. VALVE
    PE 20MM R69 #100 #58 36S00 #4.0
    PE 22MM 18S #102 #40 94D00 #3.5
    PE 24MM S14 #115 #52 G1427-36S (REF) #3.0
    PE 26MM 78P #142 #40 46JFH #3.0
    PE 28MM R37 #125 #40 46LGN #2.0
    PE 30MM 79P #130 #55 47CGJ #3.0
    PE 34MM 04K #152 #48 48DGL #3.0
    PE 36MM 80P #160 #60 48DGJ #3.0
    PE 38MM R50 #160 #50 48AJM #3.5

    PE Carburetors Dimensions

    SIZE A B C D
    PE 20MM 31 46 83 136.0
    PE 22MM 31 46 83 136.0
    PE 24MM 31 46 83 142.1
    PE 26MM 33 48 83 140.5
    PE 28MM 35 50 83 150.9
    PE 30MM 37 54 95 157.8
    PE 34MM 41 58 95 174.5
    PE 36MM 43 61 95 178.0
    PE 38MM 44 62 95 182.5

    * Images - prices - features may change at anytime without notice
